VW Fox 2005 to 2012 (5Z1 - EU market vehicles only)

- for top of piston, above top mount
- Replaces OE Ref: N10304102

- Replaces OE Ref: 1J0513353B

Genuine N90648402 Bolt (M10x35mm)

- to attach top mount to body (2 used per top mount)
- Replaces OE Ref: N90648402

Meyle 1007420009 Bumpstop, Rear

- Replaces OE Ref: 6Q0512131B

Febi 22142 Boot, Rear

- Replaces OE Ref: 1J0513425

- Replaces OE Ref: 5Z0513025E

Genuine N90517304 Bolt, Rear Shock (M10x75mm)

for bottom of rear shock
- Replaces OE Ref: N90517304

Febi 22263 Nut (M10)

for bottom of rear shock
- Replaces OE Ref: N10286110

Sachs 994165 Coil Spring, Rear

for vehicles with option code 0YA only
colour code: 1 orange, 3 blue, 1 yellow
- Replaces OE Ref: 6Q0511115AH

KYB RH5539 Coil Spring, Rear

for vehicles with option code 0YB only
colour code: 1 orange, 2 blue, 1 yellow
- Replaces OE Ref: 6Q0511115AC

Genuine 5Z0511115A Coil Spring, Rear

for vehicles with option code 0YC only
colour code: 1 white, 1 red
- Replaces OE Ref: 5Z0511115A

KYB RH6627 Coil Spring, Rear

for vehicles with option code 0YD only
colour code: 1 white, 2 red
- Replaces OE Ref: 5Z0511115B

Sachs 994421 Coil Spring, Rear

for vehicles with option code 0YJ only
colour code: 1 orange, 3 green, 1 blue
- Replaces OE Ref: 6Q0511115BD

KYB RA7024 Coil Spring, Rear

for vehicles with option code 0YK only
colour code: 1 orange, 3 green, 1 white
- Replaces OE Ref: 6Q0511115BE

KYB RA6970 Coil Spring, Rear

for vehicles with option code 0YL only
colour code: 1 orange, 1 yellow, 3 green
- Replaces OE Ref: 6Q0511115BH

KYB RA6970 Coil Spring, Rear

for vehicles with option code 0YM only
colour code: 1 orange, 2 yellow, 1 blue
- Replaces OE Ref: 6Q0511115AG

- Replaces OE Ref: 1J0512149B

Genuine 1J0512109 Spring Seat, Lower

- Replaces OE Ref: 1J0512109

Febi 31547 Rear Axle Bush

- Replaces OE Ref: 6R0501541B

Febi 26142 Bolt, Rear Axle (M12x125mm)

for rear axle bush
- Replaces OE Ref: N10409903

for rear axle bush
- Replaces OE Ref: N10106402

FAG 713610490 Wheel Bearing, Rear

- Replaces OE Ref: 6Q0598611

- Replaces OE Ref: 6Q0501117

Genuine N91006202 Bolt (M10x32mm)

- for attaching stub axle to rear beam (4 used per stub axle)
- Replaces OE Ref: N91006202
